| Ask Lasest Price | |
| Brand Name : | MXT |
| Model Number : | TDD520T560M 10W-28V |
| Price : | Negotiable |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 500Sets 30 Days |
| Delivery Time : | 30 Work Days |
10W OFDM Signal U Band 520MHz 560MHz Mesh Network Non line of sight Wireless Communication LTE Amplifier
| Item | Specification |
|---|---|
| Frequency Range | 520-560MHz (or Customized) |
| Output Power | 40dBm |
| Tx Gain | 25 ± 2 (dB) |
| Rx Gain | 10 ± 2 (dB) |
| Gain Flatness | 2.5 (dB) Peak To Peak Over Freq Band |
| EVM | <-28dB (HT20 MCS7/15 mode) |
| Noise Figure | ≤3.0(dB) |
| In/Out VSWR | Less Than 1.8:1 |
| DC Current | 3(A) @28V |
| Size(DxWxH) | 107*85*20 (mm) |
| In/Out Commector | MCX/SMA |
| Time Delay | ≤1(us) |
| Operation Temp. | -20 ~ +65 (°C) |
| I/O Map | Socket 1x3Pin 2.54mm Pin 1,2:28V Pin 3:GND |
| Supply Voltage | 28V |
| Work Mode | TDD OFDM Signal |
TDD520T560M 10W-28V amplifier is suitable for high-performance wireless broadband mesh products, using the new generation of OFDM communication technology, it has outstanding characteristics such as long transmission distance, large data throughput, strong anti-interference, and support for high-speed mobility. It can provide highly reliable wireless broadband networking links for multi node users.
Power amplifier modules can be customized according to customer requirements. The frequency bands and power indicators can be adjusted according to specific needs. This allows for greater flexibility in designing and implementing communication systems that meet specific requirements. Customized power amplifier modules can also help to optimize performance and efficiency, which can result in cost savings and improved reliability.
We offer technical support and services for our RF Power Amplifier products to ensure that they are functioning properly and providing the best possible performance.
We are available to provide assistance with the installation and setup of your RF Power Amplifier. Our team of experienced engineers can guide you through the process and answer any questions you have.
If you are experiencing any issues with your RF Power Amplifier, our team of experts can help identify the source of the problem and provide you with solutions to resolve it quickly.
|
|
